Dimensionality Reduction: PCR and PLS¶
Overview¶
When the number of predictors \(p\) is large (especially when \(p > n\), more predictors than observations), or when severe multicollinearity exists among predictors, coefficient shrinkage methods (Ridge, Lasso) become less efficient. Dimensionality reduction methods provide an alternative: instead of shrinking coefficients, they construct a smaller number of latent variables (principal components or PLS components) and regress on these.
When to Use Dimensionality Reduction¶
Dimensionality reduction is valuable when:
- \(p\) is very large — Many more predictors than observations (\(p > n\) or \(p >> n\))
- Severe multicollinearity — Predictors are highly correlated, making OLS estimates unstable
- Prediction is the goal — Interpretability of individual coefficients is less critical
- Computational efficiency — Reducing dimensionality improves computational speed
- Data comes from measurements — E.g., spectroscopy, sensor arrays where all dimensions capture noise
Key Methods¶
Principal Components Regression (PCR)¶
Unsupervised dimensionality reduction: Constructs principal components by maximizing variance in the predictor space X, then regresses the response on these components.¶
Algorithm:¶
- Standardize predictors
- Perform PCA to extract principal components
- Select optimal number of components via cross-validation
- Regress response on selected components
Advantages:¶
- Eliminates multicollinearity (components are uncorrelated)
- Handles \(p > n\) settings naturally
- Simple, well-understood method
- PCA components have clear interpretation in terms of variance
Disadvantages:¶
- Unsupervised: PCA maximizes \(X\) variance, not covariance with \(y\)
- May require many components to capture response variation
- Loss of original feature interpretability
- Components are linear combinations of all predictors
When to use: When predictor variance aligns with response variation, or as a baseline for comparison.¶
Partial Least Squares (PLS)¶
Supervised dimensionality reduction: Constructs components by maximizing covariance between predictors and response, balancing explaining variance in X with predicting y.¶
Algorithm:¶
- Standardize predictors and response
- Iteratively construct components that maximize covariance of \(X\) with \(y\)
- Select optimal number of components via cross-validation
- Regress response on selected components
Advantages:¶
- Supervised: Components are chosen to predict response
- Often requires fewer components than PCR (more efficient)
- Excellent for high-dimensional prediction problems
- Components respect covariance structure between \(X\) and \(y\)
- Originated in chemometrics; proven in practice
Disadvantages:¶
- Components still lack direct interpretability
- Theory less developed than OLS (fewer asymptotic results)
- Standardization required and can affect results
- Must tune number of components
When to use: When prediction accuracy is the goal and p is large; typically outperforms PCR.¶
Comparison: PCR vs PLS¶
| Aspect | PCR | PLS |
|---|---|---|
| Objective | Maximize variance in \(X\) | Maximize covariance of \(X\) and \(y\) |
| Component selection | Unsupervised | Supervised |
| Typical # components | Many (to capture \(y\) variation) | Fewer (aligned with \(y\)) |
| Computational complexity | O(min(n,p)³) for PCA | O(min(n,p)²) per component |
| When it excels | Variance in \(X\) important | Predicting \(y\) is goal |
| Interpretability | Same loss as PLS | Same loss as PCR |
Rule of thumb: In practice, PLS often outperforms PCR because its supervised component selection aligns better with the prediction objective.¶
Comparison with Shrinkage Methods¶
| Method | Type | Sparsity | Interpretability | High-dim Capability |
|---|---|---|---|---|
| Ridge | Shrinkage | Dense | High | Good (when \(p >> n\)) |
| Lasso | Shrinkage | Sparse | High | Good (automatic selection) |
| Elastic Net | Shrinkage | Sparse | High | Good (balanced) |
| PCR | Dimension reduction | N/A | Low | Excellent |
| PLS | Dimension reduction | N/A | Low | Excellent |
Decision tree:¶
- Need feature selection? → Lasso or Elastic Net
- Want all features + stability? → Ridge
- \(p\) very large or \(p > n\)? → PCR or PLS
- Prediction focus, high-dimensionality? → PLS
- Need interpretability? → Ridge or Lasso
Contents¶
- Principal Components Regression (PCR) — Unsupervised approach using PCA for dimensionality reduction
- Partial Least Squares (PLS) — Supervised approach maximizing covariance with response
Code Examples¶
See code/pcr_pls_examples.py for:
- Full implementation of PCR with cross-validation
- Full implementation of PLS with cross-validation
- Comprehensive model comparison
- Visualizations (scree plots, CV curves, predictions)
- Real-world housing price prediction example
Practical Guidance¶
When to Use PCR or PLS¶
Choose PCR/PLS if:¶
- \(p > n\) (more predictors than observations)
- Multicollinearity is severe
- \(p\) is large (50+ predictors) even if \(p < n\)
- You have spectroscopic or sensor data
- Prediction accuracy is paramount
- Interpretability of individual coefficients is not critical
Choose Ridge/Lasso if:¶
- Feature selection is important
- You need to understand which predictors matter
- \(p\) is moderate (< 50) and \(p < n\)
- Interpretability is crucial
- You can afford computational cost of fitting multiple models
Cross-Validation Strategy¶
Both PCR and PLS require selecting the number of components via cross-validation:
from sklearn.model_selection import cross_val_score
# Test different numbers of components
for n_components in range(1, min(n_samples, n_predictors) + 1):
cv_scores = cross_val_score(model, X_scaled, y, cv=10,
scoring='neg_mean_squared_error')
mse = -cv_scores.mean()
Always use a held-out test set to report final performance; don't trust CV error alone.
Further Reading¶
Key References¶
- Hastie, Tibshirani, Wainwright (2015). Statistical Learning with Sparsity — Chapter on dimensionality reduction
- ISLR (2013). Chapter 6 — Linear Model Selection and Regularization
- Geladi & Kowalski (1986). Partial least-squares regression — original chemometrics paper
Related Topics¶
- Regularization — Ridge, Lasso, Elastic Net (shrinkage alternatives)
- Splines and GAMs — Non-linear modeling with smoothness penalties (Chapter 7)
- Model Selection — Cross-validation, information criteria
Summary¶
Dimensionality reduction methods (PCR and PLS) offer powerful alternatives to shrinkage when:
- The predictor space is very high-dimensional (\(p >> n\) or \(p > n\))
- Multicollinearity is severe across many predictors
- Prediction accuracy is prioritized over interpretability
