Performance Metrics¶

R-squared (R-squared)¶

Definition¶

\(R^2\) represents the proportion of the variance in the dependent variable that is predictable from the independent variables:

\[ R^2 = 1 - \frac{SS_{\text{Residual}}}{SS_{\text{Total}}} \]

where:

\[ \begin{array}{lll} SS_{\text{Total}} &=& \displaystyle \sum_{i}\left(y_{i}-\bar{y}\right)^{2} \\[8pt] SS_{\text{Residual}} &=& \displaystyle \sum_{i}\left(y_{i}-\hat{y}_{i}\right)^{2} \end{array} \]

\(R^2\) values range from 0 to 1, with higher values indicating a better fit. However, \(R^2\) always increases as more predictors are added, even if they do not improve predictive power, which can lead to overfitting.

Decomposition of SS_Total¶

The total variation in \(y\) decomposes cleanly into explained and unexplained components:

\[ \begin{array}{lll} SS_{\text{Total}} &=& \displaystyle \sum_{i}\left(y_{i}-\bar{y}\right)^{2} \\[10pt] &=& \displaystyle \sum_{i}\left(\left(y_{i}-\hat{y}_{i}\right) + \left(\hat{y}_{i}-\bar{y}\right)\right)^{2} \\[10pt] &=& \displaystyle \sum_{i}\left(y_{i}-\hat{y}_{i}\right)^{2} + \sum_{i}\left(\hat{y}_{i}-\bar{y}\right)^{2} \\[10pt] &=& \displaystyle SS_{\text{Residual}} + SS_{\text{Treatment}} \end{array} \]

where \(SS_{\text{Treatment}}\) represents the variation explained by the regression model. The cross terms vanish due to the properties of OLS estimation.

Interpretation in Simple Linear Regression¶

In simple linear regression, \(SS_{\text{Treatment}}\) can be expressed in terms of the correlation coefficient:

\[ \begin{array}{lll} SS_{\text{Treatment}} &=& \displaystyle \sum_{i}\left(\hat{y}_{i} - \bar{y}\right)^{2} \\[10pt] &\approx& \displaystyle \beta^2 \sum_{i}\left(x_i - \bar{x}\right)^{2} \\[10pt] &\approx& \displaystyle n\sigma_x^2\beta^2 \\[10pt] &\approx& \displaystyle n\sigma_x^2\left(\rho\frac{\sigma_y}{\sigma_x}\right)^2 \\[10pt] &=& \displaystyle n\sigma_y^2\rho^2 \end{array} \]

Therefore:

\[ R^2 = \frac{SS_{\text{Treatment}}}{SS_{\text{Total}}} \approx \frac{n\sigma_y^2 \rho^2}{n\sigma_y^2} = \rho^2 \]

In simple linear regression, \(R^2\) is approximately the square of the correlation coefficient between \(x\) and \(y\).

References

Adjusted R-squared¶

Definition¶

Adjusted \(R^2\) accounts for the number of predictors, penalizing unnecessary complexity:

\[ \text{Adjusted } R^2 = 1 - \left(1 - R^2\right) \frac{n - 1}{n - p - 1} \]

where \(n\) is the sample size and \(p\) is the number of predictors (excluding the intercept).

Derivation of the Adjustment Factor¶

The adjustment replaces the raw sums of squares with their unbiased estimates (divided by degrees of freedom):

\[ \text{Adjusted } R^2 = 1 - \frac{SS_{\text{Residual}} / (n - p - 1)}{SS_{\text{Total}} / (n - 1)} \]

This ensures that adding a predictor only improves Adjusted \(R^2\) if the reduction in \(SS_{\text{Residual}}\) justifies the lost degree of freedom.

Key Differences from R-squared¶

Model Complexity: Adjusted \(R^2\) accounts for the number of predictors; \(R^2\) does not.
Model Comparison: Adjusted \(R^2\) is better for comparing models with different numbers of predictors.
Direction: Adjusted \(R^2\) can decrease when adding a predictor that does not improve the model, while \(R^2\) can only increase.

Other Performance Metrics¶

\[ \begin{array}{lll} \text{MAE} && \displaystyle\frac{1}{n}\sum_{i=1}^n|y_i-\hat{y}_i| \\[10pt] \text{MSE} && \displaystyle\frac{1}{n}\sum_{i=1}^n(y_i-\hat{y}_i)^2 \\[10pt] \text{RMSE} && \displaystyle\sqrt{\frac{1}{n}\sum_{i=1}^n(y_i-\hat{y}_i)^2} \end{array} \]

MAE (Mean Absolute Error): Average absolute difference between predicted and actual values. Less sensitive to outliers than MSE. Provides error in the same units as the response.
MSE (Mean Squared Error): Average squared difference. Penalizes larger errors more heavily. Used as the loss function in OLS.
RMSE (Root Mean Squared Error): Square root of MSE. Returns error to the original units of the response, making it more interpretable than MSE.

Implementation¶

import pandas as pd
import numpy as np
from sklearn.model_selection import train_test_split
from sklearn.linear_model import LinearRegression
from sklearn import metrics

# Load the dataset
url = 'https://raw.githubusercontent.com/justmarkham/scikit-learn-videos/master/data/Advertising.csv'
df = pd.read_csv(url, usecols=[1, 2, 3, 4])

# Add interaction term
df['TV:Radio'] = df['TV'] * df['Radio']

X = df[['TV', 'Radio', 'TV:Radio']]
y = df['Sales']

# Split the data
test_size_ratio = 0.3
x_train, x_test, y_train, y_test = train_test_split(X, y, test_size=test_size_ratio, random_state=42)

# Train the model
model = LinearRegression()
model.fit(x_train, y_train)

y_train_pred = model.predict(x_train)
y_test_pred = model.predict(x_test)

# Display coefficients
print(f"Intercept: {model.intercept_}")
print(f"Coefficients: {model.coef_}\n")

# R-squared
print(f"Training R^2: {model.score(x_train, y_train)}")
print(f"Testing R^2: {model.score(x_test, y_test)}\n")

# MAE
print(f"Training MAE: {metrics.mean_absolute_error(y_train, y_train_pred)}")
print(f"Testing MAE: {metrics.mean_absolute_error(y_test, y_test_pred)}\n")

# MSE
print(f"Training MSE: {metrics.mean_squared_error(y_train, y_train_pred)}")
print(f"Testing MSE: {metrics.mean_squared_error(y_test, y_test_pred)}\n")

# RMSE
print(f"Training RMSE: {np.sqrt(metrics.mean_squared_error(y_train, y_train_pred))}")
print(f"Testing RMSE: {np.sqrt(metrics.mean_squared_error(y_test, y_test_pred))}\n")
