Sampling Distributions for General OLS Estimators

Overview

This section extends the inferential results from simple linear regression to the multiple linear regression setting using matrix notation. We derive the sampling distributions of the OLS coefficient vector \(\hat{\beta}\), the residual variance estimator \(s^2\), and the \(t\)-statistic for testing individual coefficients.

---

Setup: The Multiple Linear Regression Model

Consider the model in matrix form:

\[ \mathbf{y} = \mathbf{X}\beta + \varepsilon \]

where:

• \(\mathbf{y}\) is an \(N \times 1\) vector of responses,
• \(\mathbf{X}\) is an \(N \times (p+1)\) design matrix (including an intercept column),
• \(\beta\) is a \((p+1) \times 1\) vector of unknown coefficients,
• \(\varepsilon \sim N(\mathbf{0}, \sigma^2 I_N)\) is the error vector.

The OLS estimator is:

\[ \hat{\beta} = (\mathbf{X}^T \mathbf{X})^{-1} \mathbf{X}^T \mathbf{y} \]

---

1. Sampling Distribution of beta-hat

Theorem

Under the assumptions of the linear regression model:

\[ \hat{\beta} \sim N\!\left(\beta,\; \sigma^2 (\mathbf{X}^T \mathbf{X})^{-1}\right) \]

That is, \(\hat{\beta}\) is normally distributed with:

• Mean: \(E(\hat{\beta}) = \beta\) (unbiased),
• Covariance: \(\text{Var}(\hat{\beta}) = \sigma^2 (\mathbf{X}^T \mathbf{X})^{-1}\).

Proof

Substituting \(\mathbf{y} = \mathbf{X}\beta + \varepsilon\) into the OLS formula:

\[ \hat{\beta} = (\mathbf{X}^T \mathbf{X})^{-1} \mathbf{X}^T (\mathbf{X}\beta + \varepsilon) = \beta + (\mathbf{X}^T \mathbf{X})^{-1} \mathbf{X}^T \varepsilon \]

Unbiasedness: Since \(E(\varepsilon) = \mathbf{0}\):

\[ E(\hat{\beta}) = \beta + (\mathbf{X}^T \mathbf{X})^{-1} \mathbf{X}^T E(\varepsilon) = \beta \]

Covariance: Let \(\mathbf{A} = (\mathbf{X}^T \mathbf{X})^{-1} \mathbf{X}^T\). Then \(\hat{\beta} - \beta = \mathbf{A}\varepsilon\) and:

\[ \text{Var}(\hat{\beta}) = \mathbf{A}\,\text{Var}(\varepsilon)\,\mathbf{A}^T = \mathbf{A}(\sigma^2 I_N)\mathbf{A}^T = \sigma^2 \mathbf{A}\mathbf{A}^T \]

Computing \(\mathbf{A}\mathbf{A}^T\):

\[ \mathbf{A}\mathbf{A}^T = (\mathbf{X}^T\mathbf{X})^{-1}\mathbf{X}^T\mathbf{X}(\mathbf{X}^T\mathbf{X})^{-1} = (\mathbf{X}^T\mathbf{X})^{-1} \]

Therefore \(\text{Var}(\hat{\beta}) = \sigma^2(\mathbf{X}^T\mathbf{X})^{-1}\).

Normality: Since \(\hat{\beta} - \beta = \mathbf{A}\varepsilon\) is a linear transformation of the multivariate normal vector \(\varepsilon\), \(\hat{\beta}\) is itself multivariate normal. \(\blacksquare\)

Implications

This result provides the foundation for all inference in multiple regression: confidence intervals for individual coefficients, joint confidence regions, hypothesis tests, and prediction intervals all follow from this distributional result.

---

2. Sampling Distribution of s-squared

Theorem

The residual variance estimator

\[ s^2 = \frac{1}{N - p - 1} \sum_{i=1}^N (y^{(i)} - \hat{y}^{(i)})^2 \]

has the sampling distribution:

\[ \frac{(N - p - 1)\,s^2}{\sigma^2} \sim \chi^2_{N-p-1} \]

Equivalently:

\[ s^2 \sim \sigma^2 \frac{\chi^2_{N-p-1}}{N - p - 1} \]

Key Properties

Unbiasedness: \(E(s^2) = \sigma^2\), so \(s^2\) is an unbiased estimator of the error variance.

Degrees of freedom: The \(N - p - 1\) degrees of freedom reflect the \(N\) observations minus the \(p + 1\) parameters estimated.

Independence from \(\hat{\beta}\): Under the normality assumption, \(s^2\) and \(\hat{\beta}\) are statistically independent. This independence is essential for the validity of the \(t\)-tests.

Proof

Step 1: Express residuals via projection. Define the hat matrix \(\mathbf{P} = \mathbf{X}(\mathbf{X}^T\mathbf{X})^{-1}\mathbf{X}^T\) and the residual-maker matrix \(\mathbf{M} = I_N - \mathbf{P}\). The residual vector is:

\[ \mathbf{e} = \mathbf{y} - \mathbf{X}\hat{\beta} = (I_N - \mathbf{P})\mathbf{y} = \mathbf{M}\varepsilon \]

where the last equality uses \(\mathbf{M}\mathbf{X} = \mathbf{0}\).

Step 2: Residual sum of squares as a quadratic form.

\[ \text{RSS} = \mathbf{e}^T\mathbf{e} = \varepsilon^T \mathbf{M}^T \mathbf{M}\,\varepsilon = \varepsilon^T \mathbf{M}\,\varepsilon \]

since \(\mathbf{M}\) is symmetric and idempotent (\(\mathbf{M}^2 = \mathbf{M}\)).

Step 3: Chi-squared distribution. Since \(\varepsilon \sim N(\mathbf{0}, \sigma^2 I_N)\) and \(\mathbf{M}\) is a symmetric idempotent matrix with rank \(\text{tr}(\mathbf{M}) = N - (p+1) = N - p - 1\):

\[ \frac{\varepsilon^T \mathbf{M}\,\varepsilon}{\sigma^2} = \frac{\text{RSS}}{\sigma^2} \sim \chi^2_{N-p-1} \]

Step 4: Conclusion. Dividing by the degrees of freedom:

\[ s^2 = \frac{\text{RSS}}{N - p - 1} \sim \sigma^2\frac{\chi^2_{N-p-1}}{N - p - 1} \qquad \blacksquare \]

---

3. T-Statistic for Individual Regression Coefficients

Theorem

Under the null hypothesis \(H_0: \beta_j = 0\), the test statistic:

\[ t_j = \frac{\hat{\beta}_j}{s\sqrt{v_j}} \sim t_{N-p-1} \]

where \(v_j = \left((\mathbf{X}^T\mathbf{X})^{-1}\right)_{jj}\) is the \(j\)-th diagonal element of \((\mathbf{X}^T\mathbf{X})^{-1}\).

Interpretation

The \(t\)-statistic \(t_j\) tests whether the \(j\)-th predictor contributes to the model after accounting for all other predictors. A large absolute value provides evidence that \(\beta_j \neq 0\), i.e., that the \(j\)-th variable has a statistically significant partial effect on \(y\).

The denominator \(s\sqrt{v_j}\) is the standard error of \(\hat{\beta}_j\):

\[ \text{SE}(\hat{\beta}_j) = s\sqrt{v_j} \]

Proof

Step 1: Distribution of \(\hat{\beta}_j\) under \(H_0\). From the sampling distribution of \(\hat{\beta}\), each component satisfies:

\[ \hat{\beta}_j \sim N(\beta_j, \sigma^2 v_j) \]

Under \(H_0: \beta_j = 0\):

\[ \frac{\hat{\beta}_j}{\sigma\sqrt{v_j}} \sim N(0, 1) \]

Step 2: Independent chi-squared in the denominator. From the distribution of \(s^2\):

\[ \frac{(N-p-1)s^2}{\sigma^2} \sim \chi^2_{N-p-1} \]

and this is independent of \(\hat{\beta}_j\) (since \(\hat{\beta}\) depends on \(\mathbf{P}\varepsilon\) while \(s^2\) depends on \(\mathbf{M}\varepsilon\), and \(\mathbf{PM} = \mathbf{0}\)).

Step 3: Form the \(t\)-ratio. By the definition of the \(t\)-distribution:

\[ t_j = \frac{\hat{\beta}_j / (\sigma\sqrt{v_j})}{\sqrt{s^2/\sigma^2}} = \frac{\hat{\beta}_j}{s\sqrt{v_j}} \sim t_{N-p-1} \qquad \blacksquare \]

General Confidence Interval

For a \((1 - \alpha)\) confidence interval for \(\beta_j\):

\[ \hat{\beta}_j \pm t_{N-p-1}(1 - \alpha/2)\; s\sqrt{v_j} \]

---

Example: Reproducing Linear Regression Output

Problem

Using the Advertising dataset, reproduce the main regression output for the model \(\text{Sales} \sim \text{TV} + \text{Radio} + \text{Newspaper}\) by computing coefficients, standard errors, \(t\)-statistics, \(p\)-values, and confidence intervals from scratch.

Reference

• Khan Academy: Using Least-Squares Regression Output
• Khan Academy: Interpreting Computer Regression Data

Implementation

import numpy as np
import pandas as pd
from scipy import stats

# Load the Advertising dataset
dataset_url = (
    'https://raw.githubusercontent.com/justmarkham/'
    'scikit-learn-videos/master/data/Advertising.csv'
)
advertising_data = pd.read_csv(dataset_url, usecols=[1, 2, 3, 4])

# Train/test split (70/30)
total_observations = advertising_data.shape[0]
test_set_ratio = 0.3
train_count = int(total_observations * (1 - test_set_ratio))
training_data = advertising_data.iloc[:train_count]

# Response vector y and design matrix X (with intercept column)
y = np.array(training_data.Sales).reshape(-1, 1)
n = y.shape[0]
X = np.concatenate(
    (np.ones((n, 1)), np.array(training_data.iloc[:, :-1])),
    axis=1
)
p_plus_1 = X.shape[1]  # number of parameters (including intercept)

# OLS coefficients: β̂ = (X'X)⁻¹X'y
beta_hat = np.linalg.inv(X.T @ X) @ X.T @ y

# Predicted values and residual standard error
y_hat = X @ beta_hat
s = np.sqrt(np.sum((y - y_hat) ** 2) / (n - p_plus_1))

# Variance-covariance matrix: (X'X)⁻¹
cov_matrix = np.linalg.inv(X.T @ X)

# Print regression table
print("=" * 100)
print("\t\t    coef    std err \t     t      P>|t|"
      "     [0.025      0.975] ")
print("-" * 100)

variable_names = ["Intercept", "TV", "Radio", "Newspaper"]

for name, j in zip(variable_names, range(p_plus_1)):
    coef = beta_hat[j, 0]
    v_j = cov_matrix[j, j]
    se = s * np.sqrt(v_j)
    t_stat = coef / se
    p_val = 2 * stats.t(n - p_plus_1).sf(np.abs(t_stat))
    ci_lower = coef - stats.t(n - p_plus_1).ppf(0.975) * se
    ci_upper = coef + stats.t(n - p_plus_1).ppf(0.975) * se
    print(f"{name:10}    {coef:10.4f} {se:10.3f} "
          f"{t_stat:10.3f} {p_val:10.3f} "
          f"{ci_lower:10.3f} {ci_upper:10.3f}")

print("=" * 100)

Understanding the Output

Each row of the regression table contains:

• coef: The OLS estimate \(\hat{\beta}_j\).
• std err: The standard error \(s\sqrt{v_j}\), where \(v_j = ((\mathbf{X}^T\mathbf{X})^{-1})_{jj}\).
• t: The \(t\)-statistic \(t_j = \hat{\beta}_j / (s\sqrt{v_j})\).
• P>|t|: The two-tailed \(p\)-value from \(t_{N-p-1}\).
• [0.025, 0.975]: The 95% confidence interval \(\hat{\beta}_j \pm t_{N-p-1}(0.975) \cdot s\sqrt{v_j}\).

A predictor is statistically significant at the 5% level when its \(p\)-value is less than 0.05, equivalently when its 95% confidence interval excludes zero.
